i.Node series - iNode Series Á¦Ç°Àº »ê¾÷ÀÚµ¿Á¦¾îºÐ¾ß¿¡ °³¹æÇü ºÐ»êÁ¦¾î ³×Æ®¿öÅ©ÀÇ Ç¥ÁØÀÎ LonWorks Ç÷§Æû ANSI/EIA/CEA 709.1)¸¦ äÅÃÇÑ LonWorks Àü¿ë Network I/O DeviceÀÔ´Ï´Ù.

i.Node Series Á¦Ç°¿¡ °¢Á¾ Digital, Analog Sensors ¹× Actuators¸¦ ¿¬°áÇÏ¿© Sensors°ªÀ» ¹Þ°í Actuators¸¦ Á¦¾îÇÔÀ¸·Î½á LnWorks±â¹ÝÀÇ Á¦¾î ³×Æ®¿öÅ©¸¦ ±¸ÃàÇÒ ¼ö ÀÖ½À´Ï´Ù.
i.Node PDI4DO4

Á¦Ç°Æ¯Â¡
  Digital Input 4ch, Output 4ch Á¦°ø Áö´ÉÇü ºÐ»êÁ¦¾î·Î ½Ã½ºÅÛÀÇ ¾ÈÁ¤¼º, È®À强 ³ôÀ½
  ³×Æ®¿öÅ© ±â¹ÝÀÇ ½Ã½ºÅÛÀ¸·Î ¼³Ä¡ ¹× À¯Áöº¸¼ö¿ëÀÌ ¾ç¹æÇâ Åë½Å, Multi-Target, Multi-Control °¡´É
  Áö´ÉÇü µð¹ÙÀ̽º·Î Digital, I/O Processing LNS Plug-In ÇÁ·Î±×·¥À¸·Î °£ÆíÇÑ ¼³Ä¡, °ü¸®, »ç¿ëÀÚ ÀÎÅÍÆäÀ̽º Áö¿ø
Á¦Ç°»ç¾ç

Item

Description

Processor Type

PL3150

Transceiver Type

Processor Clock

10MHz

Memory

AT29C512(32K Flash Memory)

Comm. Media

PLC(Power Line Communication)

POWER

100~240 VAC, 50/60Hz

Protocol

ANSI/EIA/CEA 709.1 Lon Talk Protocol,
ANSI/EIA/CEA 709.2 Power Line

Digital Input

Dry-contact, 30VDC Max (0~9V:ON, 9~ :OFF)

Digital Output

Relay Output, 3A Max

Dimension

92(W) x 96(H) x 82(D) mm

Operation
Temp./Humidity

-10~50¡É, 0~85%

Mounting

Wall mount type or Din Rail Base Plate type

Plug-in

Plig-In Á¾·ù

±â´É

Digital Input

µðÁöÅÐ ÀÔ·Â °¨Áö ±â´É ¼±Åà : Direct,One shot, Togle,Pulsed, Override

Digital Output

µðÁöÅÐ Ãâ·Â Á¦¾î ¼³Á¤ ±â´É : Direct,One shot, Togle,PWM, One pulse, Preset, Override

Analog Input

¾Æ³¯·Î±× ÀÔ·Â °¨Áö ±â´É ¼±Åà : ¼¾¼­ ŸÀÔ¹× Range ¼³Á¤, Filter ¼³Á¤,NV Range & Offset ¼³Á¤

User table ¼³Á¤, »óÇÑ/ÇÏÇÑ °æº¸ ¼³Á¤, Override

Analog Outpt

¾Æ³¯·Î±× Ãâ·Â Á¦¾î ±â´É ¼³Á¤ : Preset table,Input range ¼³Á¤,Scaling,Offset,Override

Loop

PID Á¦¾î±â´É ¼³Á¤ : P/I/D factor ¼³Á¤¹× P_bias,Deadband, I limit ¼³Á¤

Compare

Input NVÀÇ ºñ±³±â´É : Equal,Not Equal,Greater than equal,Less,And,Or,Ornot

Multi Function

Input NVÀÇ ºñ±³¹× ¿¬»ê ±â´É : Logic,Encoder,Counter,On time,And,Andnot,Or,Ornot,Equal

Not equal,Greater than equal,Less,Selector,Higher,lower,Add

Sub,Mul,Div,Enthalpy

Analog Control

Input NVÀÇ ºñ±³¹× ¿¬»ê ±â´É : Equal, Not equal,Greater than equal,Less,Select,Higher,lower

And,Andnot,Or,Ornot,Enthalpy,And,Sub,Mul,Div,Output NV scaling

Digital Control

Input NV¸¦ ÀÌ¿ëÇÑ Logic,Encoder,On time,Counter ±â´É

General Function Block

General Function Block
